| ブランド名: | Firepower |
| モデル番号: | MFOG-910 |
| MOQ: | 1 |
| 価格: | 1000$ |
| 支払条件: | L/C、D/P、T/T、Western Union |
| 供給能力: | 500/月 |
| Attribute | Value |
|---|---|
| Range | ±240°/s |
| Zero-bias stability (10s, 1σ) | ≤0.8°/h |
| Angular random walk | ≤0.02°/h |
| 3dB Bandwidth | ≥1000Hz |
| Zero-bias repeatability (1σ) | ≤0.8°/h |
| Scale factor nonlinearity | ≤1000ppm |
| Weight | ≤150g |
| Power Consumption | ≤1.5W |
| Parameter | Specification |
|---|---|
| Range (°/s) | ±240 |
| Scale factor (mV/°/s) | 47±5 |
| Scale factor nonlinearity (ppm) | ≤1000 |
| Zero-bias stability (10s, 1σ, °/H) | ≤0.8 |
| Zero-bias repeatability (1σ, °/H) | ≤0.8 |
| 3dB Bandwidth (Hz) | ≥1000 |
| Random walk (°/√H) | ≤0.02 |
| Power supply (V) | 5+0.25+12 |
| Power Consumption (W) | ≤1.5 |
| Impact (g) | ≥1500 |
| Acceleration (g) | ≥70 |
| Life (years) | ≥15 |
| MTBF (Calculated Assessment) | ≥100000 |
