| ブランド名: | Firepower |
| モデル番号: | MFOG-910 |
| MOQ: | 1 |
| 価格: | 700$ |
| 支払条件: | L/C、D/A、D/P、T/T、ウェスタンユニオン |
| 供給能力: | 500/月 |
| Parameter | Specification |
|---|---|
| Range (°/s) | ±240 |
| Scale Factor (mV/°/s) | 47±5 |
| Scale Factor Nonlinearity (ppm) | ≤1000 |
| Zero-bias Stability (10s, 1σ, °/H) | ≤0.8 |
| Zero-bias Repeatability (1σ, °/H) | ≤0.8 |
| 3dB Bandwidth (Hz) | ≥1000 |
| Random Walk (°/√H) | ≤0.02 |
| Power Supply (V) | 5 ±0.25 +12 |
| Power Consumption (W) | ≤1.5 |
| Impact (g) | ≥1500 |
| Acceleration (g) | ≥70 |
| Life (years) | ≥15 |
| MTBF | ≥100,000 hours |
| Parameter | VG910H1 FOG | MFOG-910 FOG |
|---|---|---|
| Angular Rate Range (°/s) | 250 | ±240 |
| Bias Stability (RMS, °/h) | 1 | ≤0.8 |
| Angle Random Walk (°/√h) | 0.015 | ≤0.02 |
| Bandwidth (kHz) | 1 | ≥1 |
| Scale Factor Stability (%) | 0.02 | ≤0.1 |
| Start-up Time | 0.03s | Fast start |
| Power Consumption (W) | 0.5 | ≤1.5 |
| Dimensions (mm) | 82 * 82 * 20 | 82 * 82 * 19.5 |
| Weight (g) | 150 | ≤150 |
| Operating Temperature (°C) | −40 ~ +70 | −40 ~ +70 |
| Storage Temperature (°C) | −55 ~ +85 | −55 ~ +85 |
| Vibration (RMS, 0.02-2 kHz, g) | 30 | 20 |
| Shock (g, 1 ms) | 1200 | ≥1500 |
| MTBF (20°C) | 100,000 h | ≥100,000 h |
| Lifetime | 15 years | ≥15 years |
